Tech Spec Comparison: Toyota Innova Crysta vs Mahindra Xylo vs Renault Lodgy

By Rahul Kapoor | on April 30, 2016

In India, the king of the MPV segment has always been the Toyota Innova. After 10 years, Toyota has finally given us the Innova Crysta, the second generation of the massively popular people carrier.

We take a look at how the new Toyota Innova Crysta fares against the Mahindra Xylo and the Renault Lodgy on paper. For this comparison, we are looking at the top of the line, most powerful variants with manual gear boxes to have an even playing field.

Dimensions:

While the Innova Crysta is the longest car among the three, however the Xylo is wider and taller. The Innova also has the shortest wheelbase while the Lodgy having the longest with 2810mm. The Crysta and the Xylo both have 55 litre fuel tanks, while the Lodgy only has a 50 litre capacity.

  Innova Crysta Xylo Lodgy
Length 4735 mm 4520 mm 4498 mm
Width 1830 mm 1850 mm 1751 mm
Height 1795 mm 1905 mm 1697 mm
Wheelbase 2750 mm 2760 mm 2810 mm
Fuel Tank Capacity 55 litres 55 litres 50 litres

Engine and Transmission:

The Renault Lodgy with the smallest size also has the smallest engine. The Lodgy comes with a 1461cc engine that is offered with two power outputs to chose from. The most powerful one generates 108hp and 245Nm of torque. The Xylo gets the 2179cc, 4-cylinder engine and produces 118hp and 280Nm of torque.

The Innova however gets a brand new 2.4 litre 4-cylinder turbo diesel engine that chips out 148hp and 343Nm of torque, making it the most powerful car in the segment. The Crysta and the Xylo both come with 5-speed manual gearboxes, however the Lodgy comes with a 6-Speed manual. The Lodgy is also the only car thats front wheel driven, while the Toyota and the Mahindra are both Rear wheel drive.

Naturally, the Lodgy will have the more fuel efficient engine because of its smaller size. The Lodgy gives a claimed, 19.98km/l, while ehe Innova with its 15.10km/l mileage is better than the Xylo's 14.02km/l.

  Innova Crysta Xylo Lodgy
Engine 2393cc / 4-cylinder / 16 valve/ Turbocharged 2179cc / 4-cylinder / 16 valve / Turbocharged 1461cc / 4-cylinder / 16 valve / Turbo Charged
Transmission 5-Speed Manual / Rear Wheel Drive 5-Speed Manual / Rear Wheel Drive 6-Speed Manual / Front Wheel Drive
Power 148hp @ 3400 rpm 118hp @ 4000 rpm 108hp @ 4000 rpm
Torque 343Nm @ 1400-2800 rpm 280Nm @ 2400-2800 rpm 245Nm @ 1750 rpm
Fuel Deisel Diesel Diesel
Fuel Economy 15.10km/l* 14.02km/l* 19.98km/l*

Wheels and Suspension:

The Xylo and the Innova both get Double Wishbone suspension at the front while the Lodgy has a McPerson Strut set up - because its Front Wheel Drive. At the rear, the Xylo has a Multi Link set up and the Lodgy gets a torsion Beam with Anti Roll Bars. The Crysta has a 4-Link set up at the rear and overall it also comes with what Toyota are calling 'Pitch and Bounce Control' which basically stabilises the car even of rough road surfaces.

Both the Lodgy and the Crysta get ventilated front disc brakes, while the Xylo has to make-do with a solid disc. The Innova however has discs which measure at 16 inches, which is why the Innova has 17 inch wheels as standard and the Xylo and the Lodgy get 15 inch rims.

  Innova Crysta Xylo Lodgy
Front Suspension Double Wishbone with Torsion bar Double Wishbone typre IFS McPherson Strut with Anti-Roll bar
Rear Suspension 4-Link with Coil Springs with pitch and bounce control Multi-Link coil spring Torsion Beam with Anti-Roll Bar
Front Brakes Ventilated Disc Disc Ventilated Disc
Rear Brakes Drum Drum Drum
Tyre Size 215/55 R17 205/65 R15 185/65 R15

Safety:

In terms of safety, all of the cars get ABS and EBD, but the Innova comes with it as standard. When it comes to airbags, the Innova not just comes with two, but three airbags at the front as standard fitment (Driver, Driver Knee & Passenger). The top trim Crysta gets 7 airbags as opposed to the Xylo and the Lodgy's only dual front set up. All three cars get rear parking sensors but the Crysta and the Lodgy get reversing cameras as well.

  Innova Crysta Xylo Lodgy
ABS with EBD Yes Yes Yes
Front Airbags Yes + Drive Knee airbag Yes Yes
Side Curtain Airbags Yes No No
Rear Parking Sensors Yes Yes Yes
Reversing Camera Yes No Yes

Features:

The Toyota and the Renault are both evenly matched in terms of features. However the Xylo might be able to seat up to 9 people (compared to maximum capacity of 8 people in the Innova and the Lodgy), the Mahinrda does lose out on some aspects like climate control and keyless entry.

Despite the fact that the Crysta does not get DRLs, it still does one above the others with tilt and reach adjustable steering and power windows with Jam protection.

  Innova Crysta Xylo Lodgy
Power Steering Yes Yes Yes
Power Windows Yes with Jam Protection Yes Yes
Adjustable Steering Tilt & Reach Tilt Tilt
Automatic Cloimate Control Yes No Yes
Keyless Entry Yes No Yes
Multifunctional Steering wheel Yes Yes Yes
Heaight Adjustable Drivers Seat Yes Yes Yes
Maximum Seating capacity 8 9 8
Daytime Running Lamps No No Yes
Fog Lamps Yes Yes Yes
Rear Defogger Yes Yes Yes
Dual-DIN Stereo with Bluetooth Yes Yes Yes
12V Power Outlet Yes Yes Yes

Verdict:

The Xylo has a decent powertrain, but does lose out in smaller details from the two, and the Lodgy loses out mostly due to its size being smaller than the competition.

The second generation Toyota Innova Crysta being being new, is more up-to-date with the market and with its offerings. The Toyota has been the segment leader but the question remains how will Toyota price the car in India. The premium features and touches is likely to drive the prices up from the older generation, but by how much remains to be seen.
